The ABB XVC724BE102 3BHE009017R0102 is a high-performance communication interface module designed for advanced automation and control systems in critical industrial environments. Part of ABB’s AC 800M controller family, the XVC724BE102 3BHE009017R0102 serves as a versatile gateway for integrating field devices, PLCs, and supervisory systems through multiple industrial protocols. Engineered for reliability, this module supports seamless data exchange in applications such as power generation, oil and gas refining, and large-scale process automation. Its dual-redundant communication ports and ruggedized design ensure continuous operation even in harsh conditions, including high electromagnetic interference (EMI) zones and extreme temperature fluctuations.
The XVC724BE102 3BHE009017R0102 is optimized for real-time data processing, featuring a high-speed backplane interface to synchronize with ABB’s AC 800M controllers like PM864 or PM865. It complies with IEC 61850 for substation automation and supports protocols such as PROFINET, Modbus TCP, and OPC UA, enabling interoperability with third-party systems. With built-in diagnostics and hot-swappable functionality, the module minimizes downtime in mission-critical operations such as grid stability management or chemical batch processing.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | XVC724BE102 3BHE009017R0102 |
| Manufacturer | ABB |
| Product Type | Communication Interface Module |
| Communication Protocols | PROFINET, Modbus TCP/IP, OPC UA, IEC 61850 |
| Data Transfer Rate | 100 Mbps (Ethernet), 12 Mbps (RS-485) |
| Redundancy Support | Dual-port Ethernet with MRP (Media Redundancy Protocol) |
| Backplane Interface | 800M Series High-Speed Bus |
| Isolation Voltage | 1,500 VAC (channel-to-ground) |
| Power Supply | 24 VDC ±10% |
| Power Consumption | 6 W (typical) |
| Operating Temperature | -40°C to +70°C |
| Humidity Tolerance | 5–95% (non-condensing) |
| Certifications | CE, UL, IEC 61131-2, RoHS |
XVC722AE101 3BHB002751R0101
Key Features
Multi-Protocol Flexibility:
The XVC724BE102 3BHE009017R0102 enables simultaneous communication across PROFINET, Modbus, and OPC UA networks, bridging legacy devices with modern IoT platforms. Its protocol-independent architecture simplifies integration into hybrid automation systems.
Industrial Robustness:
Designed for harsh environments, the module features conformal-coated PCBs and wide temperature tolerance, ensuring reliable performance in offshore platforms or desert-based solar farms.
Real-Time Diagnostics:
Embedded health monitoring tracks link status, packet loss, and latency, triggering alerts via ABB’s 800xA DCS for proactive maintenance. Hot-swap capability allows module replacement without system shutdown.
Cybersecurity Compliance:
Implements MAC address filtering, VLAN segmentation, and SSL/TLS encryption to meet IEC 62443 standards, protecting critical infrastructure from cyber threats.
Applications
Power Substation Automation:
Integrates protection relays and circuit breakers in smart grids using IEC 61850, enabling millisecond-level response for fault isolation and load balancing.
Oil & Gas SCADA Systems:
Connects remote wellhead sensors and flow computers to centralized control rooms, supporting real-time pipeline monitoring and leak detection.
Pharmaceutical Batch Processing:
Synchronizes bioreactor controllers and CIP systems via OPC UA, ensuring GMP-compliant data traceability and audit trails.
Water Treatment Plants:
Facilitates communication between PLCs and variable frequency drives (VFDs) for pump control, optimizing energy use in filtration and disinfection processes.
