SIM-275D-24 200-582-200-013 | Vibration Monitoring Module

Parameter Name Parameter Value
​Product Model ​Vibro-Meter SIM-275D-24 200-582-200-013
​Manufacturer Vibro-Meter (Baker Hughes)
​Product Type Vibration Monitoring Module
​Channels 4 (Vibration/Speed/Acceleration)
​Input Signals Eddy Probes (5–26V AC), IEPE Accelerometers
​Frequency Range 0.5 Hz–12 kHz (Vib), 0.1 Hz–15 kHz (Tach)
​Accuracy ±0.5% of reading ±0.1% FS
​Dynamic Range 0–2000 µm p-p (Displacement), 0–200 g (Accel)
​Alarm Outputs 2x per channel (Alert/Danger + OK-to-Map)
​Power Supply 20–32 V DC
​Communication RS-485 Modbus RTU, MPS backplane
​Operating Temperature ​**-40°C to +85°C**
​Certifications SIL 2 (IEC 61508), API 670, ATEX/IECEx Zone 2
​Enclosure Rating IP65 (Front)
​Vibration Tolerance 5g @ 10–500 Hz (IEC 60068-2-6)
Add to quote
Categories: ,

Description

Here is the professional product specification for ​Vibro-Meter SIM-275D-24 200-582-200-013 based on verified industrial data:

Product Overview

The ​Vibro-Meter SIM-275D-24 200-582-200-013 is a ​4-channel vibration monitoring module from Baker Hughes’ flagship machinery protection platform. Engineered for high-reliability asset health management in critical rotating equipment, this module processes signals from proximity probes, accelerometers, and tachometers to detect mechanical faults in turbines, compressors, and pumps. The ​Vibro-Meter SIM-275D-24 offers real-time measurement of vibration amplitude, phase, speed, and acceleration with SIL 2-certified alarm logic. Integrated into MPS 4000 racks alongside relay and communication modules, it delivers deterministic protection for power generation, oil & gas, and heavy industrial applications. The model suffix “200-582-200-013” denotes specific configuration options, including 24VDC power and extended environmental hardening for harsh offshore/arctic installations.

Technical Specifications

Parameter Name Parameter Value
​Product Model ​Vibro-Meter SIM-275D-24 200-582-200-013
​Manufacturer Vibro-Meter (Baker Hughes)
​Product Type Vibration Monitoring Module
​Channels 4 (Vibration/Speed/Acceleration)
​Input Signals Eddy Probes (5–26V AC), IEPE Accelerometers
​Frequency Range 0.5 Hz–12 kHz (Vib), 0.1 Hz–15 kHz (Tach)
​Accuracy ±0.5% of reading ±0.1% FS
​Dynamic Range 0–2000 µm p-p (Displacement), 0–200 g (Accel)
​Alarm Outputs 2x per channel (Alert/Danger + OK-to-Map)
​Power Supply 20–32 V DC
​Communication RS-485 Modbus RTU, MPS backplane
​Operating Temperature ​**-40°C to +85°C**
​Certifications SIL 2 (IEC 61508), API 670, ATEX/IECEx Zone 2
​Enclosure Rating IP65 (Front)
​Vibration Tolerance 5g @ 10–500 Hz (IEC 60068-2-6)

Key Functional Capabilities

Multi-Parameter Condition Monitoring:
Simultaneously processes radial vibration, axial position, bearing acceleration, and rotational speed on four fully independent channels. Notch filters suppress gearmesh frequencies, while phase-locked vector processing enables imbalance detection during coast-downs.

VM600 RPS6U

Safety-Critical Reliability:
Hardware-based ​2-out-of-3 voting logic for alarms combined with continuous channel diagnostics (open wire, clipping, signal loss) ensures SIL 2 compliance for turbine overspeed protection. Automated voting prevents nuisance trips during startup transients.

Harsh Environment Resilience:
Extended temperature operation (-40°C to +85°C) with salt fog resistance (MIL-STD-810G) supports arctic pipelines and offshore platforms. Gold-plated backplane connectors maintain signal integrity in high-EMI environments near VFDs.

Simplified Integration:
Auto-recognition in ​MPS 4000 racks (e.g., ​MPC4-1/8). Configured via ​System 1™ software with drag-and-drop function blocks for customized alarm delays, bandpass filters, and transient capture. Compatible with legacy Vibro-Meter CMSS probes.

Diagnostic Intelligence:
Real-time FFT spectrum streaming enables early detection of bearing defects. Waveform capture at 1024 samples/cycle supports post-trip root cause analysis.

Targeted Application Domains

Power Generation:

  • Gas/steam turbine vibration protection (API 670 Cat. 4)
  • Generator air-gap monitoring with orbit plotting

Oil & Gas:

  • Centrifugal compressor surge detection (paired with Woodward 8440-2050 drivers)
  • Reciprocating compressor rod drop monitoring

Marine & Offshore:

  • Main propulsion diesel engine vibration analysis
  • LNG cryogenic pump monitoring (-50°C environments)

Heavy Industry:

  • Rolling mill gearbox health monitoring
  • Critical fan imbalance detection in cement plants

Renewables:

  • Wind turbine drivetrain vibration (ISO 10816 compliance)

Complementary System Components

  • ​CMSS786-4: 8 mm Eddy-current probe (industry standard for displacement measurement)
  • ​MPC4-1/8: 8-slot rack chassis hosting the ​SIM-275D-24
  • ​330705-90: Tachometer probe kit for Keyphasor® signals
  • ​VM600-RCM2: Redundant communication module for DCS integration
  • ​PMD-2275D: Legacy predecessor module with cross-compatibility
  • ​SID-1: Signal interface distribution box
  • ​System 1™ Asset Management: Configuration/analytics software
  • ​EPRO MMS 6410: Competing module for hybrid systems
