Description
Product Overview
The ABB PPD513A-23-111615 is a modular protection and control device designed for medium-voltage power systems, delivering advanced fault detection and network stability in industrial and utility applications. Part of ABB’s Relion® protection relay family, this unit integrates comprehensive protection functions such as overcurrent, earth fault, and motor protection, ensuring rapid fault isolation and minimizing downtime. The PPD513A-23-111615 supports IEC 61850 communication protocols, enabling seamless integration into digital substations and smart grids.
Engineered for harsh environments, the ABB PPD513A-23-111615 operates reliably in temperatures ranging from -40°C to +70°C and features an IP54-rated enclosure for dust and moisture resistance. Its adaptive logic programming allows customization for complex protection schemes, while the built-in HMI with multilingual support simplifies configuration and diagnostics. The device’s dual redundant power supply and hardware-based encryption align with critical infrastructure cybersecurity standards, making it ideal for oil refineries, mining operations, and renewable energy plants.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | PPD513A-23-111615 |
| Manufacturer | ABB |
| Product Type | Numerical Protection Relay |
| Rated Voltage | 24–250 VDC / 100–240 VAC |
| Protection Functions | Overcurrent (50/51), Earth Fault (50N/51N), Motor Stall (48/66), Voltage Protection (27/59) |
| Communication Protocols | IEC 61850 (GOOSE/MMS), Modbus RTU/TCP, DNP3.0 |
| I/O Capacity | 16 Digital Inputs, 8 Relay Outputs, 4 Analog Inputs |
| Operating Temperature | -40°C to +70°C |
| Accuracy | ±1% of Setting (Current), ±0.5% (Voltage) |
| Certifications | IEC 60255, IEEE C37.90, UL 508 |
| Enclosure Rating | IP54 |
| Dimensions | 177 x 132 x 125 mm (WxHxD) |
PPD512 A10-15000 3BHE040375R1023
Key Features
The ABB PPD513A-23-111615 excels through three critical innovations:
Adaptive Motor Protection: Incorporates thermal overload modeling and rotor bar monitoring to prevent motor burnout in heavy industrial drives.
Cybersecurity Hardened: Implements ABB’s Secure Firmware Update (SFU) and role-based access control compliant with IEC 62351, mitigating cyber threats in OT networks.
Dynamic Grid Support: Voltage dip ride-through functionality maintains motor contactor stability during grid disturbances, complying with G5/4 and FRTZ standards.
Applications
The ABB PPD513A-23-111615 is pivotal in mission-critical power systems:
In steel mills, it protects rolling mill motors from phase imbalances caused by rapid load changes. Water pumping stations utilize its earth fault protection to detect insulation failures in submerged pumps.
Renewable energy plants deploy the PPD513A-23-111615 for wind turbine converter protection, while data centers rely on its voltage sag compensation to maintain UPS reliability. Mining operations leverage its rugged design for conveyor belt motor protection in dusty, high-vibration environments.
Related Products
- ABB PPD513B-24-111616: Enhanced model with arc flash detection.
- REF615: Feeder protection relay for downstream coordination.
- PPD503A-22-111614: Compact variant for space-constrained installations.
- ABB SPAJ 110C: Backup protection relay for hybrid configurations.
- REx670: Centralized controller for multi-PPD513A network management.
Product Assurance
Every ABB PPD513A-23-111615 undergoes rigorous testing per IEC 60255, including 10 kV impulse and 100-hour thermal cycling. ABB offers a 10-year lifecycle support commitment with firmware updates for evolving grid codes. Global 24/7 technical support includes ABB Ability™ Condition Monitoring and a 48-hour replacement guarantee for critical failures. Compliance with ISO 14001 ensures environmentally sustainable manufacturing practices.
