Description
Product Overview
The REXROTH PPC-R02.2N-N-Q1-NN-NN-FW is a ruggedized industrial panel PC engineered for mission-critical control applications in harsh manufacturing environments. Part of Bosch Rexroth’s PPC-R series, this 15-inch touchscreen terminal integrates an Intel® quad-core processor with industrial-grade reliability to serve as the central HMI and control interface for IndraMotion automation systems. The PPC-R02.2N-N-Q1-NN-NN-FW features an IP65-rated stainless steel front panel, 1000-nit high-brightness display, and projected capacitive touch technology for gloved operation – making it ideal for automotive assembly, steel processing, and injection molding applications. Pre-installed with Rexroth’s IndraWorks engineering suite, this unit enables seamless programming, visualization, and diagnostics of motion control systems while withstanding vibration (5g), temperature extremes (-30°C to +60°C), and chemical exposure.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | REXROTH PPC-R02.2N-N-Q1-NN-NN-FW |
| Manufacturer | Bosch Rexroth AG |
| Product Type | Industrial Panel PC |
| Display | 15″ TFT LCD (1024×768) |
| Touch Technology | Projected Capacitive (10-point multitouch) |
| Processor | Intel® Celeron® N5105 Quad-Core 2.0 GHz |
| Memory | 8 GB DDR4 RAM |
| Operating System | Windows 10 IoT Enterprise LTSC |
| Interfaces | 4x USB 3.0 |
| Protection Rating | IP65 front |
| Operating Temp | -30°C to +60°C (with SSD) |
| Vibration | 5g @ 10–150 Hz (IEC 60068-2-6) |
| Power Supply | 24V DC ±10% (3.5A typical) |
| Certifications | CE |
| Dimensions | 392 x 309 x 67 mm |
Main Features and Advantages
Sunlight-Readable Operation: 1000-nit display with anti-glare coating ensures visibility in high-ambient light environments like welding stations or outdoor logistics yards.
Glove-Compatible Touch: Projected capacitive touch supports 10-point multitouch through 5mm-thick gloves (EN 388 certified), enabling reliable operation in foundries and cold storage facilities.
Deterministic Control: Integrated real-time Ethernet (EtherCAT P) allows ≤100μs cycle times for synchronized motion control of up to 32 axes via IndraMotion MLC controllers.
PPC-R02.2N-N-Q1-NN-NN-FW
Ruggedized Construction: Stainless steel (AISI 304) front panel resists oils, coolants, and alkaline cleaners, while conformal-coated internal components prevent condensation damage.
Unified Engineering: Pre-loaded IndraWorks software enables integrated configuration of PLC logic, HMI visualization, and drive parameters on a single platform.
Application Areas
- Automotive Body Shops: Robotic welding cell control with real-time seam tracking visualization
- Plastics Machinery: Injection molding machine operation with cavity pressure monitoring
- Steel Rolling Mills: HMI for thickness control and coiling tension optimization
- Packaging Lines: Integrated motion control for robotic pick-and-place systems
- Pharmaceutical: Cleanroom-compatible terminal for vial filling machine control
- Material Handling: Warehouse automation with integrated barcode scanning
