NFCP100-S00 S3 Safety Network Communication Processor

Parameter Name	Parameter Value
Product Model	YOKOGAWA NFCP100-S00 S3
Manufacturer	Yokogawa Electric Corporation
Product Type	Safety Network Communication Processor
Safety Standard	SIL 3 (TÜV-certified IEC 61508)
Communication Protocol	FOUNDATION Fieldbus H1 (31.25 kbit/s)
Safety Functions	FF-SIF compliant (IEC 61784-3)
Port Capacity	4x FF H1 segments (max 32 devices/segment)
Response Time	≤50 ms (sensor-to-logic solver)
Diagnostic Coverage	>99% (hardware fault detection)
Redundancy	Dual processors with 2oo3 voting
Power Supply	24V DC ±10% (1.5A typical)
Operating Temp	-40°C to +70°C
Certifications	ATEX/IECEx Zone 2, DNV-GL, UL
Cybersecurity	IEC 62443-3-3 SL2, Secure Boot
Dimensions	130 x 45 x 150 mm

Add to quote

Description

Product Overview

The YOKOGAWA NFCP100-S00 S3 is a high-integrity safety network communication processor engineered for mission-critical safety instrumented systems (SIS) within Yokogawa’s ProSafe-RS platform. Designed for SIL 3 applications per IEC 61511/61508, this module enables deterministic communication between safety controllers and field devices via FOUNDATION™ Fieldbus Safety Instrumented Functions (FF-SIF). The NFCP100-S00 S3 features dual-redundant processors with 2oo3 voting logic, ensuring ≤50 ms end-to-end response times for safety shutdown commands. Its ruggedized design (-40°C to +70°C operation) and conformal-coated PCBs withstand harsh environments in oil & gas, chemical, and power generation facilities while providing hardware-enforced cybersecurity meeting IEC 62443 standards.

Technical Specifications

Parameter Name	Parameter Value
Product Model	YOKOGAWA NFCP100-S00 S3
Manufacturer	Yokogawa Electric Corporation
Product Type	Safety Network Communication Processor
Safety Standard	SIL 3 (TÜV-certified IEC 61508)
Communication Protocol	FOUNDATION Fieldbus H1 (31.25 kbit/s)
Safety Functions	FF-SIF compliant (IEC 61784-3)
Port Capacity	4x FF H1 segments (max 32 devices/segment)
Response Time	≤50 ms (sensor-to-logic solver)
Diagnostic Coverage	>99% (hardware fault detection)
Redundancy	Dual processors with 2oo3 voting
Power Supply	24V DC ±10% (1.5A typical)
Operating Temp	-40°C to +70°C
Certifications	ATEX/IECEx Zone 2, DNV-GL, UL
Cybersecurity	IEC 62443-3-3 SL2, Secure Boot
Dimensions	130 x 45 x 150 mm

Key Features & Advantages

Deterministic Safety Communication

Implements FF-SIF protocol with hardware-level time-stamping to achieve ≤1 ms jitter for critical shutdown signals, ensuring SIL 3 integrity across fieldbus networks.

Fault-Tolerant Architecture

Triple modular redundancy (TMR) with cross-channel diagnostics detects communication faults within 10 ms, preventing nuisance trips while maintaining safety availability.

NFCP100-S00 S3

Cybersecurity Hardening

Embedded TPM 2.0 module with encrypted firmware validation and role-based access control prevents unauthorized configuration changes.

Lifecycle Management

Stores device health metrics (CRC errors, retry counts) for predictive maintenance and compliance auditing per ISA 84.

Seamless Integration

Auto-discovers FF-SIF devices (e.g., pressure transmitters, shutdown valves) via Yokogawa ProSafe-RS Engineering Suite.

Application Areas

Offshore Platforms: ESD valve control via fieldbus in hazardous areas
Refineries: Fire & gas detection system communication
Chemical Plants: SIL 3 burner management system (BMS) networks
Power Generation: Turbine overspeed protection loops
LNG Terminals: Cryogenic safety valve actuation
Pharmaceutical: Sterilization chamber safety interlocks
