Description
Product Overview
GE ML351704450 029.380896/10 is a high-accuracy magnetostrictive linear position sensor engineered for critical industrial automation applications requiring micron-level precision. Originally developed by Bosch Rexroth and integrated into GE’s motion control ecosystem, this sensor provides absolute position feedback for hydraulic cylinders, presses, and precision machinery. The GE ML351704450 029.380896/10 utilizes contactless magnetostrictive technology to deliver wear-free operation with ±5µm repeatability across its 450mm stroke length. Its robust stainless-steel housing (IP67/IP69K) withstands extreme pressures, temperatures, and contaminants—making it ideal for steel mills, injection molding, and heavy mobile equipment. The sensor interfaces seamlessly with GE PLCs and drives via analog, SSI, or CANopen outputs.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | ML351704450 029.380896/10 |
| Manufacturer | GE (Licensed Bosch Rexroth design) |
| Product Type | Magnetostrictive Linear Position Sensor |
| Measuring Range | 450 mm |
| Output Signals | ±10V analog / SSI / CANopen (field-selectable) |
| Accuracy | ±0.01% FS (±45 µm) |
| Repeatability | ±5 µm |
| Resolution | 1 µm |
| Linearity Error | <±0.02% FS |
| Response Time | <0.5 ms |
| Operating Temperature | –40°C to +85°C |
| Shock Resistance | 100g (6 ms half-sine) |
| Vibration Immunity | 10g (10–2000 Hz) |
| Electrical Connection | 5-pin M12 × 1 |
| Supply Voltage | 12–30V DC |
| Current Draw | <35 mA |
| Housing Material | Stainless steel 1.4301 (AISI 304) |
| Protection Rating | IP67 / IP69K (Klein spray) |
| Compliance | IEC 60947-5-2, UL 508 |
Major Features and Advantages
Absolute Position Sensing:
- Non-volatile measurement eliminates homing routines after power loss
- Continuous position tracking without mechanical wear
Extreme Environment Robustness:
- Hermetically sealed waveguide withstands 250 bar fluid pressure
- Triple EMI shielding for stable operation near VFDs/welding systems
ML351704450 029.380896/10
Dynamic Compensation:
- Integrated Pt1000 temperature sensor auto-corrects thermal drift
- Real-time signal processing compensates for mechanical vibration
Flexible Integration:
- DIP-switch selectable output (analog/SSI/CANopen) without recalibration
- GE Proficy® and CIMPLICITY® driver support for rapid PLC integration
Maintenance-Free Operation:
- No contacting parts—rated for >100 million cycles
- Factory-calibrated for lifetime accuracy (±0.02% FS/year typical drift)
Application Domains
The GE ML351704450 029.380896/10 excels in:
- Hydraulic Cylinder Feedback: Position control in rolling mills (0.01mm accuracy)
- Injection Molding: Clamp force monitoring with ±0.05% repeatability
- Stamping Presses: Die height control in 25,000 kN systems
- Test Stands: Fatigue testing with high dynamic position recording
- Wind Turbines: Blade pitch cylinder feedback (CANopen J1939 support)
- Mobile Machinery: Boom/arm position sensing in excavators and cranes
Related Products
- GE ML350704300: 300mm stroke variant
- GE ML451704600: 600mm extended range model
- GE IC695ACC402: Analog input module for Rx3i PLCs
- Bosch Rexroth HAD2040: Hydraulic cylinder with integrated sensor
- GE DS200DCFBG1B: Drive control interface board
- Balluff BTL5-E10: Competitive magnetostrictive sensor
- GE IS220PVIBH1A: Vibration monitoring module for turbine apps
- GE Proficy Machine Edition: Configuration software
