Description
Product Overview
Model：IS420ESWBH3A
Brand：General Electric (GE Vernova)
Official Name：ESWB Industrial IONet Ethernet Switch
Applicable Platform：GE Speedtronic Mark VIe / Mark VIeS Turbine Control System
IS420ESWBH3A is an industrial unmanaged full-duplex Ethernet switch dedicated to the GE Mark VIe control system’s IONet network. It serves as the communication backbone to realize deterministic real-time data exchange between Mark VIe controllers, UCPA I/O packs, HMIs and other network devices.
This switch adopts store-and-forward switching architecture with built-in flow control, eliminating transmission collision risks for critical turbo-machinery scan cycles. It supports redundant power input to avoid single-point power failure and features ruggedized design suitable for turbine cabinet harsh environments. The hardware has reached OEM end-of-life and is available as new surplus or refurbished spare parts for legacy power plant gas turbine, steam turbine and generator control cabinet maintenance.
Key Features
- Dedicated IONet switch for Mark VIe distributed turbine control architecture
- 16 × 10/100BASE-TX RJ45 copper ports with auto-negotiation and Auto-MDI/MDI-X
- Full-duplex switching with IEEE 802.3x flow control for deterministic control data scanning
- Supports dual redundant 18–32 VDC power input for high availability configuration
- Continuous hardware self-diagnosis; front-panel LED indicators for power status, link speed, activity and duplex mode
- Robust metal housing with enhanced EMI shielding against cabinet electromagnetic interference
- Supports DIN rail or panel mounting for flexible cabinet layout
- Convection cooling design, no internal fan required
- Extended industrial temperature range for harsh industrial environments
- Fully compatible with GE ToolboxST / ControlST engineering software for network commissioning
- Compliant with all IONet timing specifications required for Mark VIe control loops
Technical Specifications
- Part Number: IS420ESWBH3A
- Type: Unmanaged IONet Ethernet Switch
- Ports: 16 × RJ45 10/100BASE-TX
- Power Supply: 18 ~ 32 VDC (nominal 28 VDC)
- Operating Temperature: -40 ℃ ~ +70 ℃
- Humidity: 5%–95% non-condensing
- Mounting: DIN rail / panel mount
- Protection Class: IP20 (must be installed inside control cabinet)
- Lifecycle Status: OEM End-of-Life
- Compatible System: GE Speedtronic Mark VIe / Mark VIeS Turbine Control System
Typical Applications
- Combined-cycle & thermal power plant gas / steam turbine Mark VIe control systems
- Generator excitation control and auxiliary machinery automation racks
- Petrochemical large turbo-compressor monitoring and control
- Industrial distributed power generation unit control panels
- Retrofit and spare part replacement for legacy GE Mark VIe control systems
Supply Information
- Condition: New Surplus / Refurbished Available
- Warranty: 12 Months
- Lead Time: Please inquire for real-time stock availability
