Description
Product Overview
Alternate Part Markings：VMIVME-017614-132, VMIVME-7698
Brand：General Electric (GE Vernova)
Official Name：UCVE Universal Control VME Embedded Controller
Applicable Platform：GE Speedtronic Mark VI Turbine Control System
This controller executes critical real-time turbo-machinery control algorithms, sequence logic, vibration monitoring, valve control and continuous fault diagnostics. It communicates with rack I/O modules via the VME backplane and exchanges process data with external systems over E-Net Ethernet and serial interfaces. It runs the QNX real-time operating system and is programmed and monitored via GE ToolboxST / ControlST software.
This assembly has reached OEM end-of-life and is available as new surplus or refurbished spare parts for legacy power plant gas turbine, steam turbine and generator control cabinet maintenance.
Key Features
- Intel Celeron 300 MHz industrial processor optimized for deterministic real-time control
- Onboard memory configuration: 32 MB DRAM + 16 MB Flash for OS and application storage
- VME64 bus interface for high-speed communication with all Mark VI I/O modules
- Front-panel I/O Interfaces:
✦ 1 × 10/100BASE-T Ethernet (RJ45) for E-Net network
✦ Dual configurable RS232 serial ports for commissioning and external communication
- Convection cooling passive heat sink design for stable 24/7 unattended operation
- Hardware watchdog timer to prevent processor lock-up during critical control cycles
- Front-panel LED indicators displaying power status, run activity, network link and fault alarms
- Continuous self-diagnosis covering memory, bus communication and internal circuit health
- Supports sequence-of-event (SOE) timestamp recording for post-fault troubleshooting
- Rugged conformal coated PCB with enhanced resistance to dust, humidity and industrial EMI
- Standard single-width 6U Eurocard VME form factor for Mark VI chassis installation
Technical Specifications
- Part Number: IS215UCVEM09A
- Hardware Platform: VMIVME-7698, Assembly PN: VMIVME-017614-132
- Processor: Intel Celeron 300 MHz
- Memory: 32MB DRAM, 16MB Onboard Flash
- Bus Standard: VME64
- Communication: 10/100M Ethernet, RS232 serial channels
- Operating Temperature: 0 ℃ ~ +60 ℃
- Humidity: 5%–95% non-condensing
- Auxiliary Power: Supplied via VME backplane
- Protection Class: IP20 (must be installed inside control cabinet)
- Lifecycle Status: OEM End-of-Life
- Compatible System: GE Speedtronic Mark VI Turbine Control System
Typical Applications
- Combined-cycle & thermal power plant gas / steam turbine Mark VI control racks
- Generator excitation control and auxiliary machinery protection systems
- Petrochemical large compressor and turbo-equipment automation
- Industrial power generation distributed machinery monitoring systems
- Retrofit and spare part replacement for legacy GE Mark VI Speedtronic control systems
Supply Information
- Condition: New Surplus / Refurbished Available
- Warranty: 12 Months
- Lead Time: Please inquire for real-time stock availability
