Description
Product Overview
The GE IC754VGI06MTD is a premium 15-inch TFT color flat panel display terminal designed for critical human-machine interface (HMI) applications in industrial automation. This unit serves as the central window into a control system, providing operators with high-visibility process graphics, real-time data trending, alarm management, and touch-screen command capabilities. As a key component of the VersaView® 1500 series, the IC754VGI06MTD is engineered for seamless integration with GE Fanuc PLCs and a wide array of third-party devices through its built-in communication ports. Its role is to translate complex machine and process data into an intuitive, actionable interface, enabling efficient monitoring, control, and troubleshooting. The implementation of the GE IC754VGI06MTD enhances operational efficiency, reduces operator error, and provides a robust platform for improving overall equipment effectiveness (OEE) in continuous process and discrete manufacturing applications.
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | IC754VGI06MTD |
| Manufacturer | GE Intelligent Platforms (now ABB) |
| Product Type | 15-inch Industrial HMI (Human-Machine Interface) |
| Display | 15″ TFT Color LCD, XGA (1024 x 768 resolution) |
| Touch Screen | Analog resistive touch screen |
| Processor | High-performance embedded processor |
| Memory | 256 MB DRAM, 128 MB Flash (typical for this variant) |
| Communication Ports | 1x RS-232, 1x RS-232/422/485, 2x USB, 1x Ethernet (10/100 BASE-T) |
| Operating System | Microsoft Windows CE .NET |
| Power Supply | 24 V DC (standard industrial voltage) |
| Operating Temperature | 0 to 50 °C (32 to 122 °F) |
| Storage Temperature | -20 to 80 °C (-4 to 176 °F) |
| Mounting | Panel-mounted (NEMA 4/12 rated front bezel when installed) |
| Certification | UL, cUL, CE, NEMA 4/12 (with proper gasket) |
Main Features and Advantages
The GE IC754VGI06MTD excels through its combination of a large, high-resolution display and rugged industrial construction. Its core advantage is the 15-inch XGA screen, which provides ample real estate for displaying complex process schematics, multiple data trends, and comprehensive alarm summaries simultaneously, drastically improving situational awareness for operators. The integrated analog resistive touch screen is durable and can be operated with a stylus or while wearing gloves, making it ideal for harsh plant floor environments.
IC754VS112CTD-HH
Powered by a reliable Windows CE operating system, this HMI offers stability and long-term performance without the vulnerabilities of commercial operating systems. Its extensive suite of communication ports, including built-in Ethernet and serial interfaces, ensures effortless connectivity to a vast range of PLCs and controllers from GE Fanuc, Rockwell Automation, Siemens, and others. The IC754VGI06MTD is designed for 24/7 operation, with a robust metal chassis and a front panel rated to NEMA 4/12 standards when properly installed, protecting it from dust, water, oil, and other industrial contaminants. This durability ensures maximum uptime and a long service life.
Application Areas
The GE IC754VGI06MTD is engineered for a vast spectrum of industrial automation applications where a large, reliable visualization platform is required. It is perfectly suited for supervisory control and data acquisition (SCADA) in water and wastewater treatment facilities, oil and gas pipelines, and electrical power distribution systems. In discrete manufacturing, it serves as a central operator station for automotive assembly lines, packaging machinery, and material handling systems. The IC754VGI06MTD is also widely used in process industries such as chemical processing, pharmaceuticals, and food and beverage, where it provides critical operator interface for batching operations, recipe management, and compliance reporting. Its rugged design makes it ideal for any control room or plant floor environment.
Related Products
IC754VSI12MTD – A 12-inch VersaView HMI model from the same series.
IC754VSI15MTD – A 15-inch model, potentially with different specifications.
IC755CKT04 – A cable kit for the VersaView series.
VersaView 5000 – An industrial computer series from GE that runs full Windows OS.
Proficy® Machine Edition – The primary GE Fanuc software used for programming this HMI and associated PLCs.
QuickPanel+ – Another series of HMI products from GE Intelligent Platforms.
Installation and Maintenance
Installation Preparation: Before installing the IC754VSI06MTD, ensure the control panel is powered down. Verify the cutout dimensions in the panel are accurate for a proper NEMA 4/12 seal. Route all communication and power cables away from high-voltage sources to prevent electromagnetic interference. Confirm the 24 VDC power supply is clean, stable, and within the specified tolerance. Have the necessary configuration file ready to load onto the HMI upon first boot.
Maintenance Recommendation: Maintenance for the IC754VSI06MTD is relatively minimal. Regularly clean the touch screen and display with a soft, lint-free cloth and appropriate cleaner to maintain visibility and touch sensitivity. Ensure the ventilation areas are not obstructed to prevent overheating. Periodically check the integrity of the panel gasket to maintain its NEMA rating. The most critical maintenance task is to regularly back up the HMI’s application configuration and operating system using the proprietary Proficy Machine Edition software. This ensures a quick recovery in the event of a hardware failure or memory corruption.
