Description
Product Overview
The FOXBORO FBM216B P0927AJ is a high-density digital output module designed for safety-critical applications within the FOXBORO I/A Series® DCS platform. This rugged module provides 32 points of isolated digital control with redundant switching paths (1oo2 architecture) for applications demanding SIL 3 safety integrity. The FOXBORO FBM216B P0927AJ features patented fail-safe circuitry that forces outputs to predetermined states upon detection of faults or power loss, ensuring failsafe shutdown in processes like emergency depressurization or fire protection systems. With arc-flash suppression technology and gold-plated relays rated for 2A @ 24V DC, it eliminates secondary failures during inductive load switching. Housed in an IP66-rated enclosure with chemical-resistant coating, the module withstands washdowns in pharmaceutical/food processing plants and sustains 50G operational shock per IEC 60068-2-27.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | FBM216B P0927AJ |
| Manufacturer | FOXBORO/Schneider Electric |
| Product Type | Safety Digital Output Module |
| Outputs | 32 channels (isolated in groups of 8) |
| Contact Rating | 2A @ 24V DC (resistive), 0.5A @ 120V AC |
| Switching Type | Form-C relay (SPDT) with arc suppression |
| Response Time | <10 ms (on/off) |
| Fault Tolerance | Dual processors with 1oo2 voter logic |
| Isolation | 1500V AC channel-to-backplane |
| Baseplate Compatibility | FBM201 (non-redundant), FBM202 (redundant) |
| Operating Temp | -40°C to 85°C (conformal coated) |
| Safety Certification | IEC 61508 SIL 3, IEC 61131-2 |
| Diagnostics | Relay weld detection, load current monitoring |
Key Features and Advantages:
Functional Safety Assurance:
Dual ARM Cortex-R52 processors execute synchronized self-tests every 2 ms, detecting >99% dangerous failures (PFH<1E-09). Output state validation uses redundant voltage/current sensing paths.
Explosion Prevention:
Integrated R-C snubber networks suppress 500V spikes from solenoid valves. Creepage/clearance >8mm prevents arcing in Group IIC hazardous areas (ATEX certified).
FBM216B
Predictive Maintenance:
Embedded health metrics track relay cycle count and contact erosion. Load impedance measurement (±5%) detects broken wires before safety function impairment.
Application Domains
The FBM216B P0927AJ dominates safety shutdown systems:
- Oil & Gas: ESD valve control in flare stacks with SIL 3 Fire & Gas loops
- Chemical Plants: Emergency quench system activation for runaway reactions
- Power Generation: Turbine overspeed protection via hydraulic trip valves
- Marine: Ballast tank control meeting DNV-GL shock/vibration standards
- Pharma: Steam sterilization (SIP) process isolation with FDA-compliant materials
Related Products
- FBM216A: Standard version without SIL 3 certification
- FBM202: Redundant baseplate for hot-swap maintenance
- FBM242: Analog input companion module (TC/mV)
- P0400VJ: Surge suppressor kit for inductive loads
- FBM230: Digital input module for safety interlock pairing
- P0927AL: Blank keying plug for configuration security
- IMTSK12: Test kit for relay contact verification
- FBM P0913RY: LED overlay for channel status indication
