DSTC175 Digital Servo Drive with Integrated Motion Controller 57310001-KN

Parameter Name	Parameter Value
Product Model	DSTC175 57310001-KN
Manufacturer	ABB
Product Type	Digital Servo Drive with Integrated Motion Controller
Rated Output Current	75A continuous (100A peak)
Output Power	15-30 kW (motor-dependent)
Input Voltage	3-phase 380-480V AC (+10%/-15%)
Control Modes	Torque, Speed, Position (CSP, CSV, CST)
Feedback Systems	EnDat 2.2, HIPERFACE DSL, Resolver, Sin/Cos 1Vpp
Communication	PROFINET, EtherCAT, Ethernet/IP, CANopen
Control Algorithms	PID with feedforward, notch filters, adaptive control
Switching Frequency	2-8 kHz (configurable)
Dynamic Response	2.5 kHz bandwidth (speed control)
Protection Class	IP20 (chassis mounting)
Operating Temperature	0°C to +45°C (with derating to +55°C)
Safety Functions	STO, SS1, SS2, SOS, SLS (SIL 3/PL e)

Add to quote

Description

Product Overview

The DSTC175 57310001-KN is a high-performance digital servo drive and motion controller manufactured by ABB, designed specifically for precision motion control applications in industrial automation and robotics. This advanced servo drive combines sophisticated drive technology with integrated motion control capabilities, providing a complete solution for demanding motion applications requiring high dynamic response, precise positioning, and synchronized multi-axis coordination. The DSTC175 57310001-KN is engineered to deliver exceptional performance in industrial environments where reliable servo control, accurate positioning, and system integration are essential for automated manufacturing processes.

Engineered with industrial durability, this servo drive features a robust design capable of withstanding harsh environmental conditions including temperature extremes, vibration, and electrical noise commonly encountered in industrial facilities. The drive incorporates advanced power electronics and microprocessor control technology that ensures accurate control of servo motors with high torque density and rapid response times. With its comprehensive safety functions, extensive communication options, and user-friendly configuration tools, the DSTC175 57310001-KN provides a flexible and reliable solution for sophisticated motion control applications across various industries.

Technical Specifications

Parameter Name	Parameter Value
Product Model	DSTC175 57310001-KN
Manufacturer	ABB
Product Type	Digital Servo Drive with Integrated Motion Controller
Rated Output Current	75A continuous (100A peak)
Output Power	15-30 kW (motor-dependent)
Input Voltage	3-phase 380-480V AC (+10%/-15%)
Control Modes	Torque, Speed, Position (CSP, CSV, CST)
Feedback Systems	EnDat 2.2, HIPERFACE DSL, Resolver, Sin/Cos 1Vpp
Communication	PROFINET, EtherCAT, Ethernet/IP, CANopen
Control Algorithms	PID with feedforward, notch filters, adaptive control
Switching Frequency	2-8 kHz (configurable)
Dynamic Response	2.5 kHz bandwidth (speed control)
Protection Class	IP20 (chassis mounting)
Operating Temperature	0°C to +45°C (with derating to +55°C)
Safety Functions	STO, SS1, SS2, SOS, SLS (SIL 3/PL e)

DSTC175 57310001-KN

Main Function Description

High-Performance Servo Control

The DSTC175 57310001-KN delivers sophisticated motion control capabilities through its advanced control architecture and powerful processing capabilities. The drive supports various operating modes including torque control for force applications, speed control for velocity regulation, and position control for precise positioning tasks. Advanced features include electronic gearing and camming for synchronized motion, flying saw applications for continuous motion, and complex interpolation for multi-axis coordination. The drive’s high dynamic response ensures minimal settling times even during high-speed movements with varying loads.

Integrated Safety Technology

A key feature of this servo drive is its comprehensive integrated safety system compliant with SIL 3/PL e standards:

Safe Torque Off (STO): Prevents unintended motor operation
Safe Stop 1 (SS1) and Safe Stop 2 (SS2): Controlled stopping sequences
Safely Limited Speed (SLS): Speed monitoring and limitation
Safe Operating Stop (SOS): Maintains position within defined limits
Safe Brake Control (SBC): Manages holding brake operation

Advanced Connectivity and Diagnostics

The drive features extensive communication capabilities through PROFINET, EtherCAT, and other fieldbus options, enabling seamless integration into automation networks. The DSTC175 57310001-KN provides comprehensive diagnostic functions including continuous monitoring of drive temperature, load conditions, and system performance. Advanced maintenance functions such as load moment of inertia identification and automatic controller optimization simplify commissioning and optimize performance throughout the system lifecycle.

Application Fields

The DSTC175 57310001-KN finds extensive application in industries requiring high-precision motion control:

Packaging Machinery: High-speed form-fill-seal equipment, cartoning systems
Printing and Converting: Web tension control, registration maintenance, cutting applications
Machine Tools: CNC applications including milling, turning, and grinding machines
Robotics: Multi-axis robot control and automation cells
Material Handling: High-speed picking, placing, and sorting systems
