DSDI110AK13 3BSE019926R1 16-Channel Digital Input Module (S800 I/O Series)

Technical Specifications

Key Features and Advantages

The ABB DSDI110AK13 3BSE019926R1 is a high-density, high-performance 16-channel digital input module from the renowned ABB S800 I/O family. It is engineered to provide reliable and accurate acquisition of binary (ON/OFF) signals from field devices like pushbuttons, limit switches, proximity sensors, and relay contacts, forming a critical link between the physical process and the control system in demanding industrial automation applications.

High Channel Density and Flexible Sourcing: With 16 isolated input channels, this module maximizes I/O point count per module, optimizing control cabinet space and system cost. It supports both sourcing (PNP) and sinking (NPN) sensor wiring configurations, which is selectable per channel group, providing exceptional flexibility to interface with a wide variety of field devices without needing additional signal conditioning modules. This versatility simplifies inventory and system design. Robust Design and Superior Noise Immunity: The module is built to ABB’s rigorous standards for industrial environments. It features high galvanic isolation (500V AC) between channel groups and the system, effectively breaking ground loops and protecting sensitive controller electronics from transients and noise commonly found in industrial settings. Its wide operating temperature range and robust construction ensure stable, long-term operation. Advanced Diagnostics and Easy Maintenance: Each channel is equipped with a bi-color LED that provides immediate visual status (healthy/fault, signal present/absent), enabling quick troubleshooting at the module. The module supports hot swapping, allowing for replacement or maintenance without powering down the entire controller rack, which is crucial for minimizing process downtime in continuous operations.

DSDI110AK14
3BSE019927R1

Product Application Scenario

In a packaging line controlled by an ABB AC 800M controller, several DSDI110AK13 modules are used to monitor the status of dozens of photoelectric sensors, safety interlocks, and valve position indicators. One module might be dedicated to sensing product presence on a conveyor, where its high noise immunity ensures reliable detection despite the nearby operation of large motors and variable frequency drives. The clear per-channel LEDs allow a maintenance technician to instantly verify which sensor is active. If a module needs replacement due to a suspected fault, it can be safely removed and a new one inserted while the line is running in a safe state, thanks to the hot-swap capability. This combination of density, reliability, and serviceability keeps production efficient. For help with wiring diagrams or integrating this module with your specific sensor types, contact our specialists on WhatsApp.

Our Commitment to Quality and Support

As your dedicated partner at SaulControl, I, Zona, and our technical team are committed to providing not just components, but reliable solutions. We understand that modules like the ABB DSDI110AK13 are the eyes of your control system. We ensure you receive genuine ABB products, supported by accurate technical data and application expertise. Our pre-sales support helps you select the right configuration, and our after-sales service, backed by a solid 1-year warranty, gives you the confidence that your investment is protected. We are here to support your project from specification to successful commissioning and beyond.

Application Areas

The ABB DSDI110AK13 is a versatile digital input solution deployed across a vast spectrum of industries. In Factory and Discrete Automation, it reads signals from machine tools, robotic cells, assembly lines, and packaging machinery. Process Industries like chemicals, oil & gas, and pharmaceuticals use it to monitor the status of pumps, valves, level switches, and safety devices. In Energy and Infrastructure, it is integral to motor control centers (MCCs), water treatment SCADA systems, and building management systems for monitoring equipment run status and alarms. Its robustness and flexibility make it a standard choice for any application within the ABB System 800xA or AC 800M ecosystem that requires reliable acquisition of discrete field signals.

Related Products

The DSDI110AK13 operates within the comprehensive ABB S800 I/O and AC 800M controller ecosystem. Key related products for a complete system include:

• ABB AC 800M Controllers (e.g., PM803F, PM805): The high-performance controllers that process the input data from the DSDI110 module.
• S800 I/O Digital Output Modules (e.g., DSDO115): For controlling actuators, solenoids, and indicators based on the logic processed from the inputs.
• S800 I/O Analog Modules (e.g., AI825, AO2040): For handling continuous process signals like temperature and pressure.
• ABB CI871 Communication Interface: An Ethernet module to network the I/O station with the controller and higher-level systems.
• ABB S800 I/O Power Supply (e.g., SD822): Provides stable 24V field power for sensors connected to the input module.
• Tension Clamp Unit (e.g., TA 527): The front connection unit for easy, reliable, and screwless wiring of field cables to the module.
• Control Builder M Engineering Software: The integrated ABB environment for hardware configuration, programming, and diagnostics of the entire system, including the DSDI110 module.

For detailed datasheets, configuration files, or a commercial quotation for the ABB DSDI110AK13 3BSE019926R1, please contact our team:

• WhatsApp: Contact on WhatsApp
• Email: sales@saulcontrol.com
• Phone: +86 18150899970

We supply genuine ABB automation components, provide expert application and integration support, and offer a full 1-year warranty. Need a different S800 I/O module or help designing a system? Contact us—we have the expertise to assist.
