DS200LDCCH1AKA Local Data Concentrator / Communication Controller

Parameter Name	Parameter Value
Product Model	GE DS200LDCCH1AKA
Manufacturer	GE Industrial Systems (Now part of GE Vernova)
Product Type	Local Data Concentrator / Communication Controller
Target System	GE Mark V Turbine Control System
Primary Function	Data acquisition, pre-processing, and serial communication interface
Communication Ports	Multiple serial ports (e.g., RS-232, RS-422, RS-485) for external communication
Backplane Interface	High-speed connection to other Mark V modules (processor and I/O)
Protocols	Supports GE-specific protocols (e.g., for CIMPLICITY) and standard serial protocols
Power Supply	Powered by the Mark V rack backplane (typically +5V DC)
Operating Temperature	0°C to +70°C (32°F to +158°F)
Status Indicators	LED indicators for power, communication activity, and faults
Mounting	Plugs into a dedicated slot in the Mark V rack assembly

Add to quote

Description

Product Overview

The GE DS200LDCCH1AKA is a high-performance communication and control module designed for the GE Mark V gas and steam turbine control system. This module serves as a vital interface within the Mark V rack, functioning as a Local Data Concentrator (LDC) and communication hub. The primary role of the GE DS200LDCCH1AKA is to manage data acquisition from various I/O modules within the chassis, pre-process this information, and facilitate high-speed communication with the system’s central processing units (like the DS200PCCAG1ACB). It also handles communication with external devices, such as operator workstations, other turbine controllers, or a plant-wide Distributed Control System (DCS), via serial communication protocols.

As an integral component of the robust Mark V architecture, the GE DS200LDCCH1AKA is engineered for reliability and deterministic performance in the demanding environment of a power generation facility. It acts as a data traffic controller within the turbine control cabinet, ensuring that critical process variables, status points, and alarm information are efficiently and reliably exchanged between the field I/O, the control logic solvers, and the operator interface. The value of the GE DS200LDCCH1AKA lies in its ability to offload communication tasks from the main processor, enhance system modularity, and provide a reliable gateway for data, thereby contributing to the overall high availability and responsiveness of the turbine control system. Its failure could lead to a loss of operator visibility and control, making it a key component for safe and efficient turbine operation.

Technical Specifications

Parameter Name	Parameter Value
Product Model	GE DS200LDCCH1AKA
Manufacturer	GE Industrial Systems (Now part of GE Vernova)
Product Type	Local Data Concentrator / Communication Controller
Target System	GE Mark V Turbine Control System
Primary Function	Data acquisition, pre-processing, and serial communication interface
Communication Ports	Multiple serial ports (e.g., RS-232, RS-422, RS-485) for external communication
Backplane Interface	High-speed connection to other Mark V modules (processor and I/O)
Protocols	Supports GE-specific protocols (e.g., for CIMPLICITY) and standard serial protocols
Power Supply	Powered by the Mark V rack backplane (typically +5V DC)
Operating Temperature	0°C to +70°C (32°F to +158°F)
Status Indicators	LED indicators for power, communication activity, and faults
Mounting	Plugs into a dedicated slot in the Mark V rack assembly

DS200LDCCH1AKA

Main Functional Description

The GE DS200LDCCH1AKA delivers critical performance through its role as a centralized data manager and communication gateway. A core function is its ability to aggregate data from multiple I/O modules (digital, analog) within the Mark V rack. It can perform preliminary data processing, such as scaling and alarm checking, before presenting the data to the main control processors. This offloads computational burden from the main CPU, allowing it to focus on high-speed control algorithms. The module typically features multiple serial communication ports, which are used to establish links with HMIs (Human-Machine Interfaces) for operator control, with engineering workstations for configuration, and with other controllers for coordinated plant operations.

System Integration and Diagnostics: The GE DS200LDCCH1AKA is essential for integrating the Mark V system into the broader plant ecosystem. It can communicate with a plant DCS using standard protocols, relaying turbine status and receiving setpoints. This makes the turbine’s operational data accessible from a central control room. The module includes diagnostic capabilities that monitor the health of its internal circuits and the status of its communication links. Status LEDs provide immediate visual feedback for maintenance personnel, indicating power, transmit/receive activity on the serial ports, and any internal fault conditions. This simplifies troubleshooting and helps maintain system availability.

Application Areas

The GE DS200LDCCH1AKA is deployed in power generation facilities utilizing the GE Mark V turbine control system. Its primary application is in simple and combined-cycle power plants, where it is a fundamental component in the control system for GE Frame 5, 6, 7, and 9E gas turbines. It is also used in steam turbine control applications.

Within the turbine control cabinet (TCC), the GE DS200LDCCH1AKA acts as a critical communication nerve center. It is indispensable for providing the data link between the turbine’s control logic and the operator interface, allowing engineers to monitor turbine parameters like speed, temperature, and vibration, and to issue start/stop commands. It also facilitates historical data logging and sequence-of-events (SOE) recording by time-stamping and transmitting alarm data. In essence, this module enables the supervisory control and data acquisition (SCADA) functionality that is vital for the operation and management of the turbine-generator set.
