CPAR-08AE-14293 Servo Drive

Parameter Name	Parameter Value
Product Model	PARKER CPAR-08AE-14293
Manufacturer	Parker Hannifin Corporation
Product Type	Servo Drive
Rated Current	8A RMS continuous
Input Voltage	200–240V AC 1-phase (+10%/-15%)
Control Modes	Torque, Velocity, Position, Cyclic Synchronous
Communication	EtherCAT (CoE)
Feedback	EnDat 2.2
Safety	STO (SIL 3/PL e)
Switching Frequency	16 kHz (programmable)
Control Loop Update	≤62.5 μs
Operating Temp	0°C to +55°C (derating above 40°C)
Protection Class	IP20
Dimensions	70 x 145 x 165 mm (WxHxD)
Certifications	CE, UL, cULus

Add to quote

Description

Product Overview

The PARKER CPAR-08AE-14293 is a high-performance servo drive engineered for precision motion control in demanding industrial automation applications. Part of Parker Hannifin’s Compax3 C3P series, this compact drive delivers 8A continuous current (16A peak) with advanced control algorithms for dynamic positioning of servo motors. Designed for single-phase 200–240V AC operation, the CPAR-08AE-14293 supports EtherCAT communication for real-time synchronization in multi-axis systems while providing integrated safety functions (STO/Safe Torque Off). Its convection-cooled IP20 design enables high-density cabinet installation, making it ideal for packaging machinery, robotics, and semiconductor manufacturing where space efficiency and rapid response times (≤62.5μs cycle time) are critical.

Technical Specifications

Parameter Name	Parameter Value
Product Model	PARKER CPAR-08AE-14293
Manufacturer	Parker Hannifin Corporation
Product Type	Servo Drive
Rated Current	8A RMS continuous
Input Voltage	200–240V AC 1-phase (+10%/-15%)
Control Modes	Torque, Velocity, Position, Cyclic Synchronous
Communication	EtherCAT (CoE)
Feedback	EnDat 2.2
Safety	STO (SIL 3/PL e)
Switching Frequency	16 kHz (programmable)
Control Loop Update	≤62.5 μs
Operating Temp	0°C to +55°C (derating above 40°C)
Protection Class	IP20
Dimensions	70 x 145 x 165 mm (WxHxD)
Certifications	CE, UL, cULus

Main Features and Advantages

Dynamic Control Performance: Parker’s Advanced Auto-Tuning algorithm compensates for mechanical resonances and load variations, achieving settling times <5ms for high-acceleration applications like pick-and-place robots.

Cableless Feedback: Direct support for Parker GVM series motors with EnDat 2.2 eliminates resolver cables, reducing wiring costs and signal noise.

Integrated Safety: Hardware-enforced STO (Safe Torque Off) meets ISO 13849-1 PL e and IEC 61800-5-2 SIL 3 requirements without external relays.

CPAR-08AE-14293

Multi-Axis Synchronization: EtherCAT enables ≤1ms cycle times for coordinated motion across 32+ axes – critical for CNC machining and electronic assembly.

Energy Efficiency: Regenerative braking circuitry feeds 95% of deceleration energy back to the grid, reducing heat dissipation by 40% vs. conventional drives.

Application Areas

Robotic Arms: Precise joint control for SCARA/articulated robots
Packaging Lines: Synchronized motion for filling/capping systems
Semiconductor Handling: Wafer positioning with nanometer repeatability
Printing Machinery: Register control for web tension management
Automated Assembly: Screwdriving/pressing force profiling
Medical Devices: Fluid dispensing pump control
