Description
Overview
Essential details：AI05 | ABB | AI Module 8-CH Galv. isol. HART
Product Description
The ABB AI05 is an analog input module commonly used in ABB’s distributed control systems (DCS) or other automation systems. Here are the details of the product:
Product characteristics
Multi-channel design:
With 8 independent input channels, multiple signal sources can be processed simultaneously.
Each channel supports 4-20mA and 1-5VDC signal inputs.
Isolation function:
Electrical isolation is provided between the input channels and between each channel and the external power supply to prevent signal interference.
High precision:
Provides high-precision signal conversion to ensure data accuracy.
Reliability:
Designed for industrial environments to ensure long-term stable operation.
Compatibility:
Compatible with ABB’s control systems and may have some compatibility with other third party systems.
AI05
Product parameter
ABB Type Designation:AI05
Catalog Description:AI Module, 8-CH Galv. isol. HART
Long Description:4-20mA, 1-5VDC, Individual Channels Isolated, with dedicated HART modem & ADC for each CH. Use Base xBS01-EPD.
Product Type:I-O_Module
Product Net Depth / Length:254 mm
Product Net Height:508 mm
Product Net Width:101.6 mm
Product Net Weight:0.4 kg
APPLICATION AI05 | ABB | AI Module 8-CH Galv. isol. HART
Industrial automation: Used in factory automation, process control and other fields.
Data acquisition: used to collect a variety of analog signals, such as temperature sensors, pressure sensors and other output signals.
DCS system: Used for data acquisition and processing as part of ABB’s DCS system.
Technical specification
Number of channels: 8 channels.
Signal type: 4-20mA and 1-5VDC.
Isolation mode: Electrical isolation between channels and between channels and power supplies.
