Description
Overview
Essential details：A6500-CC A6500-CC System Communication Card
Product Description
The ModBus and Rack Interface Module is designed for high reliability for the plant’s most critical rotating machinery. It reads parameters from all AMS A6500 ATG modules and outputs these parameters through ModBus TCP/IP and/or ModBus RTU (serial).
In addition, OPC UA is available for data transmission to third party systems.
This 1-slot monitor is used together with other AMS A6500 ATG monitors to build a complete API 670 machinery protection monitor. Applications include steam, gas, compressors, and hydro turbo machinery.
Operators are provided machinery health parameters in the control environment for seamless integration. The module powers local graphical displays at the protection rack for machine and instrumentation readout. Either ModBus TCP/IP or ModBus RTU or OPC UA can be configured, or for redundant path, can be used simultaneously.
A6500-CC 9199-00120
Product parameter
3U size, 1-slot plug-in module decreases cabinet space requirements in half from traditional 6U size cards.
API 670 compliant, hot-swappable module.
Password protected user configuration.
Self-checking facilities include monitoring hardware, power input, and hardware temperature.
Includes SD-Card to support AMS 6500 ATG Prediction functionality
SNTP time synchronisation
2000 free assignable modbus registers
APPLICATION A6500-CC A6500-CC System Communication Card
Model: A6500-CC.
Brand: Emerson.
Series: CSI 6500 Mechanical Health Monitoring System.
Function: Communication and frame interface module for reading the parameters of all CSI A6500 ATG modules and output them via Modbus TCP/IP, Modbus RTU or OPC UA.
Power Supply: 24 VDC.
Input: 4 digital or analog inputs.
Output: 2 digital or analog outputs.
Communication interface: Support Modbus RTU, Modbus TCP, EtherNet/IP.
Memory: 128 MB RAM and 128 MB ROM.
Operating temperature range: -20°C to 70°C.
Protection level: IP67.
Size: 150mm x 100mm x 50mm.
Weight: 500g.
Features:
The 3U size, single-slot plug-in module saves half of the cabinet space compared to the traditional 6U size card.
API 670 compliant, hot-swappable module.
Self-check function, including software, power input and hardware temperature monitoring.
Password protection User configuration.
Supports redundant data communication to improve system reliability.
Integrated predictive capabilities, including PeakVue technology and bandpass filters.
High-speed counting capability, can quickly and accurately process high frequency pulse signals
