Description
Overview
Essential details：8I74T401500.010-1 | ACOPOSinverter P74 | integrated EMC filter and brake chopper
Product Description
The 8I74T401500.010-1 is an ACOPOSinverter P74 series inverter module manufactured by B&R Industrial Automation for the control of small and medium-sized turbines with high speed and high reliability. Here are the details of the product:
Product characteristics
Integrated features:
Integrated dynamic brake transistor.
Internal 24VDC power supply.
Integrated EMC filter.
Input/output interface:
Digital input: 6, 24VDC (Max. 30V), input circuit as source or sink, sampling time 8ms.
Safety input (STO, safe torque off) : 1, 24VDC, input impedance 1.5kΩ, sampling time 4ms.
Analog inputs: 3, support 0-10V or ±10V voltage, or 0-20mA (or 4-20mA) current, 10-bit resolution, sampling time 2ms.
Digital output: 1, 24VDC, maximum 30V, output circuit as source or sink, sampling time 2ms.
Relay output: 2, can switch the load at 30VDC/250VAC.
Analog output: 1, support 0-10V or 0-20mA output, 10-bit resolution, update time 2ms.
Mechanical characteristics:
Dimensions: Width 180mm, height 404mm (330mm without shielding plate), depth 232mm.
Weight: 6.75kg.
Protection level: IP20.
Electrical characteristics:
Input voltage: 3-phase 380-500VAC.
Power: 15kW (20HP), maximum current 36.7A.
8I74T400400.010-1
Product parameter
MATERIAL NUMBER:
8I74T401500.01P-1
DESCRIPTION:
ACOPOSinverter P74, 3x 380 to 500 V, 15 kW, integrated EMC filter and brake chopper, shield plate included in delivery, POWERLINK interface
For revision information, see the following model numbers:
8I74T401500.010-1
8I0IF108.400-1
APPLICATION 8I74T401500.010-1 | ACOPOSinverter P74 | integrated EMC filter and brake chopper
1. Industrial automation equipment
Machinery manufacturing: Used to control machine tools, robots and other equipment.
Material handling: Suitable for small conveyor belts, lifts and other equipment.
Packaging machinery: Used for small labeling machine, bag making machine, etc.
Wood processing: such as automatic lathes, saws, milling machines, etc.
Metal processing: such as bending machine, welding machine, cutting machine, etc.
2. General industrial applications
Pumps and compressors: Used to control the operation of pumps and compressors.
Fan and ventilation equipment: suitable for industrial fan and ventilation system speed regulation.
Braking control: Support dynamic braking function.
Torque control: Suitable for scenarios requiring precise torque control.
