5AP981.1505-01 | Safety Input Module

Parameter Name Parameter Value
Product Model ​5AP981.1505-01
Manufacturer B&R Industrial Automation (ABB Group)
Product Type Safety Input Module
Channels 8 (Dual-channel, CAT 4)
Input Types 24V DC (PNP/NPN), NAMUR, Dry Contact
Response Time ≤ 2 ms (configurable)
Diagnostics Channel asymmetry, cross-fault, wire break, overload
Isolation 500V AC (field-to-logic)
Safety Standards IEC 61508 SIL 3, ISO 13849 PL e, IEC 62061
Connection Spring clamp (0.25–1.5 mm²)
Operating Voltage 24V DC (19.2–28.8V)
Current Consumption 80 mA (typ.)
Operating Temp -25°C to +60°C
Certifications UL 508, CE, cULus
Add to quote
Categories: ,

Description

Product Overview

The ​B&R 5AP981.1505-01 is an advanced ​safety input module designed for high-reliability functional safety systems within B&R Automation’s X20 and EPIC® platforms. Engineered to SIL 3 (IEC 61508) and PL e (ISO 13849) standards, this module integrates 8 dual-channel safety inputs with ​cross-circuit monitoring for emergency stop circuits, safety gates, and light curtains. The ​B&R 5AP981.1505-01 supports diverse sensor types (NAMUR, mechanical contacts, solid-state) with configurable pulse extension and filter times down to 2 ms. Its galvanic isolation (500V AC) and built-in diagnostics detect wire breaks, shorts, and contact welding in real time. Compatible with ​SafeLOGIC™ safety controllers, this module enables seamless integration of safety and standard logic while reducing cabinet space by 40% versus conventional safety relays.

Technical Specifications

Parameter Name Parameter Value
Product Model ​5AP981.1505-01
Manufacturer B&R Industrial Automation (ABB Group)
Product Type Safety Input Module
Channels 8 (Dual-channel, CAT 4)
Input Types 24V DC (PNP/NPN), NAMUR, Dry Contact
Response Time ≤ 2 ms (configurable)
Diagnostics Channel asymmetry, cross-fault, wire break, overload
Isolation 500V AC (field-to-logic)
Safety Standards IEC 61508 SIL 3, ISO 13849 PL e, IEC 62061
Connection Spring clamp (0.25–1.5 mm²)
Operating Voltage 24V DC (19.2–28.8V)
Current Consumption 80 mA (typ.)
Operating Temp -25°C to +60°C
Certifications UL 508, CE, cULus

Key Features and Advantages:

Flexible Safety Integration:
Auto-teaching function adapts to sensor characteristics (e.g., mechanical bounce time). Configurable OSSD (Output Signal Switching Device) inputs support light curtains with muting sequences.

Advanced Diagnostics:
Embedded asymmetry monitoring (±0.5 ms) detects delayed switching. Per-channel LEDs visualize fault states (green = OK, red = fault, yellow = diagnostic active).

5AP1130.156C-000

Seamless Engineering:
Configuration via ​B&R Automation Studio Safe with pre-certified function blocks. Automatic validation of safety parameters (e.g., category, reaction time) per project requirements.

Robust Performance:
Overvoltage protection (60V DC/50 ms) and reverse polarity protection. Conformal-coated PCB withstands humidity up to 95% non-condensing.

Application Domains

The ​5AP981.1505-01 is critical for safety-critical automation:

  • ​Automotive Manufacturing: Robotic cell safety gates with < 5 ms reaction time
  • ​Packaging Lines: Light curtain monitoring for high-speed fillers (EN ISO 13855 compliance)
  • ​Material Handling: Emergency stop chains for AS/RS cranes (PL e Cat. 4)
  • ​Plastics Processing: Two-hand control stations guarding injection molding machines
  • ​Pharma: Cleanroom-compatible safety systems (ISO 14644 Class 5)
  • ​Metals: Roller conveyor emergency stops with vibration resistance (5g)
