0190-15779 Robotic End Effector

Parameter Name	Parameter Value
Product Model	AMAT 0190-15779
Manufacturer	Applied Materials, Inc.
Product Type	Robotic End Effector
Wafer Compatibility	300mm (12-inch)
Material	Reinforced alumina ceramic composite
Vacuum Rating	≤10<sup>-8</sup> Torr (UHV compatible)
Positioning Accuracy	≤±0.05mm (3σ)
Gripping Force	0.5–5N (programmable)
Sensors	Integrated wafer presence detection
Operating Temperature	-40°C to +150°C
Cycle Life	>1,000,000 cycles
Interface	AMAT-standard robotic arm mount
Weight	420g ±10g
Cleanroom Class	ISO Class 1 (ISO 14644-1)

Add to quote

Categories: DCS, Other

Description

Product Overview

The Applied Materials (AMAT) 0190-15779 is a precision-engineered robotic end effector module designed for ultra-clean wafer handling in semiconductor fabrication equipment. As a critical component of AMAT’s advanced material processing systems, this end effector enables sub-millimeter positioning accuracy for 300mm wafers in high-vacuum environments up to 10<sup>-8</sup> Torr. The AMAT 0190-15779 integrates with CENTURA® and ENDURA® platform robots to transport wafers between load locks, process chambers, and metrology stations with near-zero particulate generation. Its proprietary ceramic-composite construction minimizes electrostatic discharge (ESD) risks while maintaining dimensional stability across -40°C to 150°C thermal cycles. Engineered for Class 1 cleanroom compatibility, the AMAT 0190-15779 reduces wafer defects through anti-stiction coatings and edge-gripping technology that eliminates backside contamination. With over 1 million cycle MTBF certification, this module ensures tool uptime in 24/7 semiconductor manufacturing where wafer yield protection is paramount.

Technical Specifications

Parameter Name	Parameter Value
Product Model	AMAT 0190-15779
Manufacturer	Applied Materials, Inc.
Product Type	Robotic End Effector
Wafer Compatibility	300mm (12-inch)
Material	Reinforced alumina ceramic composite
Vacuum Rating	≤10<sup>-8</sup> Torr (UHV compatible)
Positioning Accuracy	≤±0.05mm (3σ)
Gripping Force	0.5–5N (programmable)
Sensors	Integrated wafer presence detection
Operating Temperature	-40°C to +150°C
Cycle Life	>1,000,000 cycles
Interface	AMAT-standard robotic arm mount
Weight	420g ±10g
Cleanroom Class	ISO Class 1 (ISO 14644-1)

Key Features and Advantages

Particulate-Free Operation: The AMAT 0190-15779 utilizes diamond-like carbon (DLC) coatings on contact points, reducing particle adders to <0.05 particles/cm² per transfer – critical for sub-10nm node manufacturing.

Thermal Stability: Near-zero thermal expansion (CTE 0.8 ppm/°C) maintains ±5μm positional accuracy during rapid thermal cycling in CVD/PVD chambers.

Advanced Diagnostics: Embedded strain gauges detect wafer slip events within 50ms, triggering automatic recovery sequences to prevent scrap wafers.

ESD Protection: Surface resistivity <10⁶ Ω/sq dissipates electrostatic charges below 50V, eliminating electrostatic discharge damage to sensitive devices.

Quick-Change Design: Tool-less replacement capability reduces mean repair time to <15 minutes using AMAT’s proprietary alignment fixtures.

Application Areas

The AMAT 0190-15779 excels in semiconductor manufacturing environments requiring contamination-sensitive wafer handling:

Logic/DRAM Fabs: High-volume transfer between etch/deposition modules in 3D NAND production lines
AI Chip Manufacturing: Handling ultrathin wafers (<100μm) for advanced packaging (CoWoS, InFO)
Compound Semiconductor: GaN/SiC wafer transport in high-temperature MOCVD tools
Metrology Integration: Precise placement on review SEMs and AFM systems
Vacuum Cluster Tools: Multi-chamber transfer in atomic layer deposition (ALD) systems
R&D Facilities: Prototype handling for novel substrate materials (glass, flexible)
